Nadia Tube Fittings is a reliable manufacturer and supplier of Bulkhead Union Elbows based in Kuala Lumpur, Malaysia. We specialize in precision-engineered tube fittings that ensure dependable fluid and gas connections. Our Bulkhead Union Elbows are crafted to create a secure 90-degree connection through panels or barriers, guaranteeing leak-proof and vibration-resistant performance. Made from top-notch materials like stainless steel, brass, carbon steel, and various alloys, these fittings offer outstanding strength, corrosion resistance, and durability. They find extensive use in instrumentation, hydraulic, pneumatic, chemical, oil & gas, and marine applications where dependable panel-mounted connections are crucial.
Our Bulkhead Union Elbows are built from sturdy materials tailored to meet specific application needs—typically stainless steel (304/316), brass, carbon steel, or specialized alloys. This careful selection ensures exceptional mechanical strength, resistance to corrosion, and the ability to handle pressure. These fittings boast impressive tensile strength, fatigue resistance, and leak-proof sealing, even in high-pressure or high-vibration settings. With precision threads and ferrule designs, they provide a strong mechanical grip, ensuring longevity and reliability. For carbon steel variants, protective coatings can be applied to enhance wear and corrosion resistance.
| Mcneil part no. | Equivalent Part no. Type 1 | Equivalent part no Type 2 | ODT-ØT(INCHES) | C | BODY HEX F | ODT-ØT1(INCHES) | Ø E | D | L | NUT HEX W | L1 |
| 1-BUD | -100-61 | 1BC1 | 1/16 | 0.43 | 5/16 | 1/16 | 0.05 | 0.34 | 0.84 | 5/16 | 1.24 |
| 2-BUD | -200-61 | 2BC2 | 1/8 | 0.60 | 7/16 | 1/8 | 0.09 | 0.50 | 1.50 | 7/16 | 2.02 |
| 3-BUD | -300-61 | 3BC3 | 3/16 | 0.63 | 9/16 | 3/16 | 0.12 | 0.54 | 1.59 | 7/16 | 2.11 |
| 4-BUD | -400-61 | 4BC4 | 1/4 | 0.70 | 5/8 | 1/4 | 0.19 | 0.60 | 1.03 | 9/16 | 2.27 |
| 5-BUD | -500-61 | 5BC5 | 5/16 | 0.73 | 11/16 | 5/16 | 0.25 | 0.64 | 1.81 | 5/8 | 2.39 |
| 6-BUD | -600-61 | 6BC6 | 3/8 | 0.76 | 3/4 | 3/8 | 0.28 | 0.66 | 1.87 | 11/16 | 2.45 |
| 8-BUD | -810-61 | 8BC8 | 1/2 | 0.86 | 7/8 | 1/2 | 0.41 | 0.90 | 2 | 7/8 | 2.80 |
| 10-BUD | -1010-61 | 10BC10 | 5/8 | 0.86 | 1-1/16 | 5/8 | 0.50 | 0.96 | 2.06 | 1 | 2.86 |
| 12-BUD | -1210-61 | 12BC12 | 3/4 | 0.86 | 1-3/16 | 3/4 | 0.63 | 0.96 | 2.31 | 1-1/8 | 3.11 |
| 14-BUD | -1410-61 | 14BC14 | 7/8 | 0.86 | 1-3/8 | 7/8 | 0.72 | 1.02 | 2.53 | 1-1/4 | 3.33 |
| 16-BUD | -1610-61 | 16BC16 | 1 | 1.04 | 1-5/8 | 1 | 0.88 | 1.23 | 2.81 | 1-1/2 | 3.77 |
At Nadia Tube Fittings, we are the leading supplier, manufacturer, and exporter of Bulkhead Union Elbow in Kuala lumpur, Malaysia. Our state-of-the-art manufacturing facilities, strategically located in the Malaysia, empower us to provide high-quality solutions tailored to your specific requirements. With an extensive inventory of various premium materials, we are well-equipped to meet your needs efficiently. Our dedication to excellence and operational efficiency ensures we consistently maintain available stock, making us your trusted partner for reliable Union Cross fittings in various applications.
Nadia Tube Fittings is a leading supplier and stockist of premium Bulkhead Union Elbow in Kuala lumpur, Malaysia. Our products are widely utilized across various industries, recognized for their strength, durability, and reliable performance in connecting multiple pipe sections. We are committed to delivering exceptional service and ensuring high levels of customer satisfaction. Our advanced manufacturing techniques set us apart in the fittings industry, enabling us to consistently provide top-quality Union Cross fittings while effectively addressing the unique requirements of our customers.
Contact us to get a quick quote for your requirement.
You’ll find Bulkhead Union Elbows widely used in industries that demand reliable 90-degree panel-mounted connections. In oil & gas and petrochemical facilities, they facilitate the safe and efficient routing of process fluids and gases. In hydraulic and pneumatic systems, they guarantee leak-proof performance in compact setups. In marine and offshore sectors, they withstand seawater corrosion and vibration stress. Additionally, they are utilized in instrumentation, power generation, chemical processing, and automotive industries, where secure and precise fluid control is essential. Their blend of strength, corrosion resistance, and ease of installation makes them a top choice for challenging industrial applications.
