Duplex Stainless Steel Condensate Pots

Home > Duplex Steel> Duplex Stainless Steel Condensate Pots

Nadia Tube Fittings stands out as a top manufacturer and supplier of Duplex Stainless Steel Condensate Pots right in Kuala Lumpur, Malaysia. They specialize in providing high-quality solutions tailored for steam and instrumentation systems across critical industries. Crafted from Duplex Stainless Steel grades like S31803 and S32205, these condensate pots are expertly designed to gather and cool condensate from steam lines before it reaches measuring instruments. This design not only ensures precise pressure measurement but also protects sensitive equipment from the harshness of high-temperature steam, all while boasting impressive durability in corrosive environments.

Duplex Stainless Steel Type A Condensate Pots with 2 Ports Manufacturer Kuala lumpur, Duplex Stainless Steel Type B Condensate Pot with Red Oxide Coated Dealer George town, S31803 Duplex Stainless Steel Condensate Pots Type C Supplier Malaysia, 2205 Duplex Stainless Steel Type A Condensate Pot Exporter In Ipoh, Duplex Stainless Steel Type B Condensate Pots with 3 Ports Manufacturer Kuala lumpur, Duplex Stainless Steel Type C Condensate Pot with Galvanized Plating Kuala lumpur, Malaysia.

What makes Duplex Stainless Steel Condensate Pots truly remarkable are their outstanding mechanical properties. They feature high tensile and yield strength, along with resistance to pitting, crevice corrosion, and stress corrosion cracking, even in challenging chloride-rich and high-pressure settings. Thanks to their dual-phase microstructure, they offer superior toughness compared to regular stainless steel, guaranteeing long-lasting performance even under extreme thermal and mechanical stress. These condensate pots come in various capacities, end connections, and pressure ratings, all manufactured to meet international standards, ensuring both precision and safety in demanding applications.

Duplex Stainless Steel Condensate Pots Specifications

Standard : DIN, ASTM, BS and all International Standards.
Number of Ports : 2 ports upto 8 ports, refer to the section below for arrangements.
Working Pressure : 6000 PSIG(41.34 MPa).
Pressure Rating : 1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI.
Header Inlet : 1” Female Bsp or Npt threaded to ASME B16.1 or Flanged inlet optional.
Header Outlet/drain : None / or ¼”Male Bsp or Npt threaded to ASME B16.1 or 150# cast fitting.
Pipe size : 2″, 3″, 4″, 5”, 6” and larger size upon request.
Pipe Schedule : 40, 80, 160, XX seamless pipe.
Total Length : Pipe length 8″,10″,12″ and larger length upon request.
Thread Connections : NPT as per ANSI B1.20.1,Socket weld as per ANSI B16.11, Butt weld as per ANSI B16.9.

Sizing Of Duplex Stainless Steel Condensate Pots

P NPT – F	Capacity (Internal Vol.0)cm 3±5%	Pressure Rating PSIG	T mm	L mm	B mm
1/4”	150	1800	2.05	135	50.08
1/4”	300	1800	2.05	225	50.08
1/4”	400	1800	2.05	290	50.08
1/4”	500	1800	2.05	350	50.08
1/4”	1000	1800	4.06	275	88.09
1/4”	2250	1800	5.02	435	120
1/4”	3785	1800	5.02	680	120
1/2”	1000	1800	4.06	275	88.09
1/2”	2250	1800	5.02	435	102
1/2”	3785	1800	5.02	680	102
3/4”	1000	1800	4.06	275	88.09
3/4”	2250	1800	5.02	435	102
3/4”	3785	1800	5.02	680	102

Types of Duplex Stainless Steel Condensate Pots

Duplex Stainless Steel Type A Condensate Pot with Zinc Plating Price in Kuala lumpur, DSS Type B Condensate Pots Supplier in George town, 2205 Duplex Stainless Steel Type C Condensate Pot Manufacturer in Malaysia, Duplex Stainless Steel Type A Condensate Pot with Galvanized Plating Manufacturer & Price in Ipoh, Duplex Stainless Steel Condensate Pot Type B Supplier in Kuala lumpur, Duplex Stainless Steel Type C Condensate Pot with Red Oxide Coated In Kuala lumpur, Malaysia.

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Duplex Stainless Steel Condensate Pots in Kuala lumpur, Malaysia

At Nadia Tube Fittings, We are proud to be the largest supplier, manufacturer, and exporter of Duplex Stainless Steel Condensate Pots in Kuala lumpur, Malaysia Our cutting-edge solutions cater to all your piping needs. With state-of-the-art production facilities strategically located in the Malaysia, we maintain a vast inventory of over 16,000 tons of premium-quality materials, ensuring we have the stock readily available to meet your demands.

Duplex Stainless Steel Condensate Pots Uses

You’ll find Duplex Stainless Steel Condensate Pots widely utilized in industries where accurate measurement, equipment protection, and corrosion resistance are paramount. The oil and gas sector relies on them for offshore rigs, refineries, and petrochemical plants, while the power generation industry incorporates them in steam turbines and boilers. They’re also crucial in chemical, marine, and pharmaceutical sectors, where exposure to aggressive chemicals and chlorides is a common challenge. With their exceptional strength, corrosion resistance, and meticulous engineering, Duplex Stainless Steel Condensate Pots deliver reliable performance, extend the lifespan of instruments, and help maintain operational efficiency even in the toughest service environments.
