Home > Hydraulic Straight Coupling
A hydraulic straight coupling is a fitting that connects two hydraulic hoses or tubes in a straight line, ensuring a secure, leak-proof, and continuous flow of hydraulic fluid. These couplings are built to withstand high-pressure conditions and are commonly found in hydraulic systems where efficiency, reliability, and strength are essential. They come in various materials like carbon steel, stainless steel, brass, or alloy steel, offering excellent durability and resistance to corrosion based on the specific application.
Designed with precision, hydraulic straight couplings help maintain proper alignment between connected components, which prevents pressure drops and fluid leaks. You can find them with different end connection types, including BSP, NPT, JIC, ORFS, and metric threads, making them compatible with a wide range of hydraulic equipment standards. Their sturdy construction allows them to perform effectively in both low- and high-pressure hydraulic circuits, showcasing their versatility.
At Nadia Tube Fittings, we are the largest supplier, manufacturer, and exporter of Hydraulic Straight Coupling in Kuala lumpur, Malaysia. Our advanced manufacturing facilities, strategically positioned in the Malaysia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.
| Metric Tubing | |||||||||
|
Tube O.D mm |
A mm |
C mm |
D mm |
W inch |
Min bore mm |
||||
|
3 |
35.3 |
15.3 |
22.1 |
7/16 |
2.4 |
||||
|
4 |
37.4 |
16.1 |
24.2 |
7/16 |
3.0 |
||||
|
6 |
41.2 |
17.7 |
26.2 |
1/2 |
4.8 |
||||
|
8 |
43.2 |
18.6 |
28.2 |
9/16 |
6.4 |
||||
|
10 |
46.2 |
19.5 |
31.0 |
11/16 |
7.9 |
||||
|
12 |
51.2 |
22.0 |
31.0 |
13/16 |
9.5 |
||||
|
16 |
52.0 |
22.0 |
31.8 |
15/16 |
12.7 |
||||
|
18 |
53.5 |
22.0 |
33.3 |
1.1/16 |
15.1 |
||||
|
20 |
55.0 |
22.0 |
34.8 |
1.3/16 |
15.9 |
||||
|
25 |
65.1 |
26.5 |
40.5 |
1.3/8 |
22.2 |
||||
Contact us to get a quick quote for your requirement.
Nadia Tube Fittings is a leading supplier and stockist of premium Hydraulic Straight Coupling in Kuala lumpur, Malaysia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.
These couplings are widely used across industries such as construction, agriculture, mining, marine, and manufacturing, where hydraulic systems drive heavy-duty machinery and equipment. You’ll find them in applications like excavators, loaders, presses, pumps, cylinders, and other hydraulic assemblies that need reliable straight connections for efficient fluid transmission under high-pressure conditions.
Please feel free to contact us if you need any further information or for enquiry.
