Stainless Steel 316ti Ball Valve

Home > Stainless Steel > Stainless Steel 316ti Ball Valve

Nadia Tube Fittings is a reliable manufacturer and supplier of Stainless Steel 316Ti Ball Valves based in Kuala Lumpur, Malaysia. They provide strong and efficient flow control solutions tailored for demanding industrial settings. These valves feature a quarter-turn operation, which allows for quick shutoff, dependable sealing, and smooth regulation of both liquids and gases. Crafted from SS 316Ti, a titanium-stabilized austenitic stainless steel, these valves boast impressive resistance to intergranular corrosion, high temperatures, and aggressive substances. With a focus on precision engineering and compliance with international standards, Nadia Tube Fittings distributes SS 316Ti Ball Valves throughout Malaysia and to industries around the globe.

Stainless Steel 316ti Instrumentation Ball Valve Manufacturer in Kuala lumpur, Stainless Steel DIN 1.4571 Compression Ball Valve in Ipoh, SS UNS S316ti 35 Hydraulic Ball Valve Supplier in George town, X5CrNi18-10 Stainless Steel High Pressure Ball Valve Price List in Kuala lumpur, 316ti Stainless Steel 2 Way Ball Valve Price in Ipoh, DIN 1.4571 SS 3 Way Ball Valve in Kuala lumpur, Malaysia, UNS S316ti35 Stainless Steel 4 Way Ball Valve Price in Malaysia, 316ti Stainless Steel 5 Way Ball Valve Supplier in George town

The composition of Stainless Steel 316Ti Ball Valves includes chromium, nickel, and 2–3% molybdenum, with titanium added for stabilization. This distinctive chemical makeup significantly boosts resistance to pitting, crevice corrosion, and carbide precipitation, especially during extended exposure to high temperatures. On the mechanical side, these valves deliver high tensile and yield strength, outstanding toughness, and a long service life, even in tough operating conditions. The precision-machined ball and seat ensure a bubble-tight shutoff, smooth operation, and minimal torque requirements, making them reliable for critical applications.

Stainless Steel 316ti Ball Valve Specifications

VALVE SIZE	1/8″ TO 2″ / 6 MM TO 50 MM
THREAD	NPT, BSPP, BSPT, JIC, METRIC, UNF
CONNECTION	THREADED, TUBE END, BUTT WELD, SOCKET WELD, WELD NIPPLE, FLANGED, SAE
FUNCTION	2 WAY, 3 WAY, 4 WAY, 5 WAY,
PRESSURE RATING	1500 PSI, 3000 PSI, 6000 PSI, 10000 PSI, 15000 PSI, 20000 PSI
SEAL RING MATERIAL	PTFE, PVDF, DELRIN, PEEK, GRAPHITE
STANDARD	ISO , DIN , ANSI , API , ASME , AWWA , MSS ,
MEDIA	HYDRAULIC OIL, AIR, WATER, GAS, STEAM, HOT WATER , COLD WATER , SEA WATER , CHEMICAL
MEDIA TEMPERATURE	(-120* C TO 500*C )RANGE AS PER PRESSURE
BODY TYPE	BAR STOCK
BRAND NAME	TU-LOK
PACKING DETAILS	BOX PACKING, WOODEN PALLET
EQUIVALENT BRANDS	SWAGELOK, PARKER, DK-LOK, HAMLET, OLIVER VALVES, HOKE
APPLICATION	MATERIAL HANDLING EQUIPMENT, EARTH MOVING MACHINERIES , POWER GENERATING PLANT , STEEL MANUFACTURING PLANT , MINING INDUSTRIES , CHEMICAL PROCESSING MACHINES , PIPING LINE , PAINT INDUSTRIES , TRUCKS AND TRAILERS , AUTOMATION , AGRICULTURE MACHINES , AEROSPACE & DEFENCE EQUIPMENTS,

Stainless Steel 316ti Ball Valve Chemical Composition

Grade		C	Ni	Si	N	S	Mn	P	Cr	Mo
SS 316Ti	min.	–	10.0	–	–	–	–	–	16.0	2.00
SS 316Ti	max.	0.08	14.0	0.75	0.10	0.030	2.0	0.045	18.0	3.00

Stainless Steel 316ti Ball Valve Mechanical Properties

Grade	Tensile Strength (MPa) min	Elongation (% in 50mm) min	Yield Strength 0.2% Proof (MPa) min	Hardness
Grade	Tensile Strength (MPa) min	Elongation (% in 50mm) min	Yield Strength 0.2% Proof (MPa) min	Rockwell B (HR B) max
SS 316Ti	515	35	205	75

Stainless Steel 316ti Ball Valve Equivalent

STANDARD	UNS	WERKSTOFF NR.	AFNOR	EN	JIS	BS	GOST
SS 316Ti	S31635	1.4571	Z6CNDT17‐12	X6CrNiMoTi17-12-2	SUS 316Ti	320S31	08Ch17N13M2T

Top Stainless Steel 316ti Ball Valve Manufacturing Company in Kuala lumpur

At Nadia Tube Fittings, we are the largest supplier, manufacturer, and exporter of Stainless Steel 316 Ball Valve in Kuala lumpur, Malaysia. Our advanced manufacturing facilities, strategically positioned in the Malaysia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfil your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands.

Types of Stainless Steel 316ti Ball Valve

Stainless Steel 316ti Instrumentation Ball Valve Price in Malaysia, UNS S316ti 35 Stainless Steel Compression Ball Valve Supplier in George town, X5CrNi18-10 Stainless Steel Hydraulic Ball Valve Manufacturer in Kuala lumpur, DIN 1.4571 Stainless Steel High Pressure Ball Valve in Ipoh, 316ti Stainless Steel 2 Way Ball Valve Supplier in George town, UNS S316ti35 Stainless Steel 3 Way Ball Valve in Kuala lumpur, Malaysia, DIN 1.4571 Stainless Steel 3 Way Ball Valve Price List in Kuala lumpur, 316ti SS 5 Way Ball Valve Price in Ipoh

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

Largest Manufacturer and Supplier of Stainless Steel 316ti Ball Valve in Kuala lumpur, Malaysia

Nadia Tube Fittings is a leading supplier and stockist of premium Stainless Steel 316ti Ball Valve in Kuala lumpur, Malaysia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the metal industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

Stainless Steel 316ti Ball Valves Uses

These ball valves find extensive use in various sectors, including oil and gas, chemical and petrochemical processing, power generation, pharmaceuticals, marine engineering, and water treatment. They are particularly well-suited for high-temperature systems, boiler applications, heat exchangers, and offshore environments where resistance to corrosion and heat is crucial. Their capability to handle corrosive fluids and varying pressures makes them a top choice for essential fluid handling and shutoff tasks. By combining durability, corrosion resistance, and operational efficiency, Stainless Steel 316Ti Ball Valves guarantee safe and reliable performance in industrial flow control systems.
