T Port Ball Valve

Home > T Port Ball Valve

A T-port ball valve is a unique kind of 3-way ball valve that provides flexible flow control in piping systems. It has a T-shaped opening in the ball, which allows fluid to flow through all three ports or just between two selected ones, depending on how the valve is positioned. This type of valve is often used in systems that need to mix or divert fluids, making it a compact and efficient choice for complex flow routing without the hassle of multiple valves.

T Port Ball Valve Supplier in Kuala lumpur, 3 way T-port Floating Ball Valve Price List in George town, 3 ASME B16.5 2013 Ball Valve Manufacturer in Malaysia, T Port End Flanged Ball Valve in Ipoh, ASTM A479 SS316 Ball Valve Exporter in George town, ASTM A216 WCB Manufacturer in Kuala lumpur, ASTM A216 WCB Ball Valve In Kuala lumpur, Malaysia.

One of the biggest benefits of a T-port ball valve is its ability to handle various flow functions with just one valve. It can channel flow from one source to two different destinations, mix fluids from two inlets into a single outlet, or allow full flow through all three ports simultaneously. This flexibility makes it perfect for applications in chemical processing, food and beverage production, water treatment systems, and other industrial processes where effective fluid control is crucial.

T Port Ball Valve Specification

TYPE :	3 way T-port Floating Ball Valve
PORT :	Full Bore
SIZE :	15 mm to 100mm NB
Pressure Rating :	ASME #150PN 20 ASME #300PN 50
Temperature Range	35 Deg C to 280 Deg C (Soft Seated)
Body Materials	Stainless Steel / Carbon Steel / Alloys
Design Standard	API 6D rev 23; ISO 17292 rev 2004
End Flanges	ASME B16.5 2013
Face to Face Dimension	Non Standard , As per Manufacturer Std
Fire safe design	API-607 Rev 2010
Testing	API 598 Rev 2009
Sour Service	NACE MOR 0175 Rev 2009
Documents	BS/EN 10204-3.1 REV 2004

T Port Ball Valve Supplier in Kuala lumpur, 3 way T-port Floating Ball Valve Price List in George town, 3 ASME B16.5 2013 Ball Valve Manufacturer in Malaysia, T Port End Flanged Ball Valve in Ipoh, ASTM A479 SS316 Ball Valve Exporter in George town, ASTM A216 WCB Manufacturer in Kuala lumpur, ASTM A216 WCB Ball Valve In Kuala lumpur, Malaysia.

Top T Port Ball Valve Manufacturing Company in Kuala lumpur

At Nadia Tube Fittings, we are the largest supplier, manufacturer, and exporter of T Port Ball Valve in Kuala lumpur, Malaysia. Our advanced manufacturing facilities, strategically positioned in the Malaysia, enable us to deliver high-quality solutions to meet your specific requirements. With a robust inventory of over 16,000 tons of top-grade materials, we are well-equipped to fulfill your needs promptly. Our commitment to excellence and efficiency ensures we always have the available stock to support your demands

Material Code for T Port Ball Valve

SR.NO.	PART NAME	STAINLESS STEEL	CARBON STEEL	QTY
1	BODY	ASTM A351 CF8M	ASTM A216 WCB	1
2	END CONN.	ASTM A351 CF8M	ASTM A216 WCB	1
3	END CONN. SIDE	ASTM A351 CF8M	ASTM A216 WCB	1
4	END CONN. BACK	ASTM A351 CF8M	ASTM A216 WCB	1
5	BALL	ASTM A276 SS316	ASTM A276 SS316	1
6	STEM	ASTM A479 SS316	ASTM A479 SS316	1
7	SEAT	PTFE	PTFE	2
8	SEAT SEAL	GRAPHITE / INCONEL	GRAPHITE / INCONEL	2
9	GLAND	SS316	MS	1
8	GLAND BEARING	DELRIN	DELRIN	1
10	SPACER	SS316	SS316	1
12	STEM THRUST WASHER	GFT	GFT	1
13	BODY SEAL	GRAPHITE	GRAPHITE	1
14	STEM O-RING	VITON	VITON	1
15	BODY SEAL	GRAPHITE	GRAPHITE	2
16	END CONN. O-RING	VITON	VITON	2
17	CAVITY	PTFE	PTFE	2
18	STUD	ASTM A193 GR.B8M	ASTM A193 GR.B7	4
19	NUT	ASTM A193 GR.8M	ASTM A193 GR.2H	4
20	STUD	ASTM A193 GR.B8M	ASTM A193 GR.B7	4
21	NUT	ASTM A193 GR.8M	ASTM A193 GR.2H	4
22	STUD	ASTM A193 GR.B8M	ASTM A193 GR.B7	4
23	NUT	ASTM A193 GR.8M	ASTM A193 GR.2H	4
24	LEVER	SS410	SS410	1
25	ALLEN BOLT	MS	MS	1
26	STOPER	MS	MS	1

Types of T Port Ball Valve

We offer These Products as per DIN, ISO, JIS or ANSI Standard.

T Port Ball Valve Supplier in Kuala lumpur, Malaysia

Nadia Tube Fittings is a leading supplier and Stockist of premium T Port Ball Valve in Kuala lumpur, Malaysia. Our products are widely utilized across various industries, and we are committed to delivering exceptional service and ensuring high customer satisfaction. Our distinctive finishing techniques set us apart in the fittings industry. We are dedicated to consistently providing top-quality products while effectively addressing the needs of our customers.

T Port Ball Valve Uses

When it comes to operation, the T-port valve can usually be rotated 180° or 270°, depending on the handle design and flow needs, which makes it easy for operators to switch between different flow paths. Constructed from materials like stainless steel, brass, or PVC, these valves are built to last in a variety of environments. Their design also cuts down on the number of fittings and joints required in a system, simplifying installation and reducing potential leak points.
